Inorganic high-power series
Inorganic packaging process, AR film design for various UV wavelengths, light output efficiency >97%, organic content 0%, reliable lifespan exceeding 30,000 hours, used in disinfection, medical, and high-power catalysis fields.
| Picture | Model | Size(mm) | Substrate | Test/Max IF(mA) | VF(V) | Spectral radiant flux Φe(mW) | Peak Wavelength（nm） | Radiation Degree(Deg） | Application |
|---|---|---|---|---|---|---|---|---|---|
|
HGC-L68FU29N8H | 6.8*6.8*1.7 | Ceramics | 700/700 | 10.0~14.0 | 200~400 | 290~300 | 120 | Industrial healthcare |
|
HGC-L68FU34N8H | 6.8*6.8*1.7 | Ceramics | 700/700 | 8.0~13.0 | 200~400 | 335~345 | 120 | Industrial solidification |
Inorganic series
Inorganic packaging process, high light output efficiency, high reliability, organic content 0%, reliable lifespan exceeding 30,000 hours, used in high-power disinfection applications.
| Picture | Model | Size(mm) | Substrate | Test/Max IF(mA) | VF(V) | Spectral radiant flux Φe(mW) | Peak Wavelength（nm） | Radiation Degree(Deg） | Application |
|---|---|---|---|---|---|---|---|---|---|
|
HGC-L35BU27N4F | 3.5*3.5*1.7 | Ceramics | 500/500 | 5.0～7.0 | 50~100 | 265～285 | 120 | Industrial healthcare |
Semi inorganic series
Air-tight semi-inorganic packaging process, gold-tin eutectic soldering process. Its characteristics include a stable and reliable structure, wide market coverage, and large-scale manufacturing capabilities.
| Picture | Model | Size(mm) | Substrate | Test/Max IF(mA) | VF(V) | Spectral radiant flux Φe(mW) | Peak Wavelength（nm） | Radiation Degree(Deg） | Application |
|---|---|---|---|---|---|---|---|---|---|
|
HGC-L35BU27N1A | 3.5*3.5*1.5 | Ceramics | 30/40 | 5.0～7.0 | 2.5～8.0 | 265～285 | 120 | Industrial healthcare |
|
HGC-L35BU27N4C | 3.5*3.5*1.7 | Ceramics | 100/120 | 5.0～7.0 | 10～25 | 265～285 | 120 | Industrial healthcare |
