COB series
Product parameters
| Picture | P/N | Product Description | Data Rate (Gbit/s) | TX | RX | TX_Min (dBm) | TX_Max (dBm) | RX_Max(dBm) | Power Consumption (W) | Reach | Temperature (deg C) | Application |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
OH-PY85S-G00 | SFP28 SR | 25G | 850nm VCSEL | PIN | -8.4 | 2.4 | 2.4 | 1 | 100M | 0~70 | 25G Ethernet,5G fronthaul CPRI/eCPRI networks |
|
OH-QQ85S-N00 | QSFP+ 40G SR4 | 40G | 850nm VCSEL | PIN | -7.6 | 1 | 2.4 | 1.5 | 100m@OM3/150m@OM4 | 0~70 | 40G Ethernet,4*10G Ethernet, data centers |
|
OH-QQ85S-N02 | QSFP+ 100G SR4 | 100G | 850nm VCSEL | PIN | -8.4 | 2.4 | 2.4 | 1.5 | 70M@OM3/100M@OM4 | 0~70 | 100G Ethernet,data center core routers,campus networks |
|
OH-RD-BS159 | SNAP12 T12R12 | 120G | 850nm VCSEL | PIN | NA | NA | NA | NA | NA | 0~70 | Military products |
